THÔNG TIN SẢN PHẨM


  C360-CN SD PTZ Camera, 480TVL 10X Optical zoom
C-360 Color Video PTZ Camera which adopted 10x optical zoom with high performance 480 TVL Quality, it equipped with AV,S-Video output, ideally suited for Web video conferencing system, remote education system etc.

Chi Tiết Sản Phẩm





Model

C360-CN


Sensor

CCD

1/4" Color CCD

Minimum Scene Illumination

0.05 Lux

White Balance

AUTO/Manual

Gain Control

Auto

Back-light Compensation

On/Off

Electronic shutter

1/50-1/10,000s

Horizontal resolution

480 TVL

S/N Ratio

> 50dB

Lens

Focus

AUTO

Iris

AUTO/Manual

Zoom

10x Optical Zoom

f=3.8-38 mm ,F=1.8

Video Output

VIDEO VBS: 1.0Vpp at 75ohm;

S-VIDEO (ONLY FOR SONY LENS)

Communication

EIA/RS-422

EIA/RS-232(Bidirectional)

Baud Rate

2400/4800/9600 bps

Patrol tours

4

Pattern tours

4

Preset

64

Privacy Mask Zone

4

Power On Active

Auto pan scan or Patrol(Programmable)

Speed Matching Function

Support

OSD Menu

Support

Image Auto Flip

Support

Pan Speed

0-280 degrees/s

Tilt Speed

0-100 degrees/s

Pan rotation angle

360 degrees continuously

Tilt rotation angle

180 degrees

Auto Pan Scan

Support

Boundary Scan

0-359 degrees(programmable)

Remoter Control

IR Wireless remote control P/T/Z(10M)

Power

DC 12V+-10%; 1.2A

Temperature and humidity

0°-60°C, 0-95% RH(non-condensation)
