THÔNG TIN SẢN PHẨM


  HD390 2.0M HD PTZ Camera, HOV 70 degree, DVI Video output,Iris AUTO/Manual
2.0 Megapixel ,Full HD Camera experience 1080i@60 vivid images, equipped with 10x optical zoom lens, enhancing your video conferencing, distance learning, training meeting, courtrooms or remote medical with natural and smooth video images Support USB Interface which is easy to installation and transfer high-quality video streaming.

Chi Tiết Sản Phẩm





Model

HD390


SenSor

Sensor

1/2.8" CMOS 2.0 Mega Pixel

Minimum Scene illumination

4.0 mm F1.6 fixed lens 1.0 Lux at F1.2

White Balance

AUTO/Manual

Gain Control

AUTO

Back-light compensation

ON/OFF

Electronic shutter

1/50~1/120,000S E-shotter

S/N Ratio

>50db

Lens

Focus

4.0 mm Fixed Lens HOV 70 degree

Iris

AUTO/Manual

Video Output

HD-SDI

HDMI

Video format

1080P@60, 1080P@30, 1080P@25, 1080P@24, 1080i@60, 1080i@50, 720P@60, 720P@50

Control Decoder

EIA/RS-485

Communication

EIA/RS-232(Bidirectional)

PTZ Control Protocol

VISCA,PELCO-P,PELCO-D

Baud Rate

4800/9600 bps

Patrol tours

4

Preset

64

Save status after Power off

Support

Speed Matching Function

Support

OSD Menu

Support

Image Auto Flip

Support

Pan Speed

0-100 degrees/s

Tilt Speed

0-80 degrees/s

Pan Rotation Angle

359 degrees

Tilt Rotation Angle

90 degrees

Auto Pan Scan

Support

Boundary Scan

0-359 degrees(Programmable)

Remoter Control

IR Wireless remote control P/T/Z

Power

DC12V ±10% 1.2A

Operation Temperature

-10℃~60℃

Environmental humidity

0-95%RH(non-condensation)

Length X width X high

124x120x145mm/220x175x220mm(NET/PACKAGE)

Weight

800g/1300g(NET/PACKAGE)
