THÔNG TIN SẢN PHẨM


  HD380-K1,10x Optical zoom, DVI/HDMI Video PTZ Camera, 720P/1080P,HDMI output
2.0 Megapixel Full HD Camera experience 1080i@60 vivid images, equipped with 10x optical zoom lens, enhancing your video conferencing, distance learning, training meeting, courtrooms or remote medical with natural and smooth video images. DVI-I connector is suited for DVI-D analog component which provide high-quality video display.It support HD-SDI Video output for further distance transmission. Features: Private Tooling design High Definition PTZ camera Fast and smooth video handling Power ON-OFF switch Work & Standby LED indicator Speed Match Auto/Manual focus/brightness/WB RS-232C/VISCA Protocol Lens/Dome OSD menu Boundary scanning Standby & wakeup status Swap video format button HDMI/HD-SDI Video output.

Chi Tiết Sản Phẩm









Model

HD380-K1


SenSor

Sensor

1/2.5 model, primary color CMOS, 2.1 M compatible

Minimum Scene lllumination

1Lux at F1.8

White Balance

AUTO/Manual

Gain Control

AUTO

Back-light compensation

ON/OFF

Electronic shutter

1/5~1/4000S

S/N Ratio

>50db

Lens

Focus

AUTO

Iris

AUTO/Manual

Zoom

10x Optical Zoom

1/3.6model f=4.5-45mm F1.8-2.2

Video Output

HD-SDI

HDMI

Video format

1080P@30,1080P@25,1080P@24,1080I@60, 1080I@50,720P@60,720P@50

Control Decoder

EIA/RS-485

Communication

EIA/RS-232 (Bidirectional)

PTZ Control Protocol

VISCA,PELCO-P,PELCO-D

Baud Rate

9600/38400 bps

Patrol tours

4

Preset

64

Save status after Power off

Support

Speed Matching Function

Support

OSD Menu

Support

Image Auto Flip

Support

Pan Speed

0-100 degrees/s

Tilt Speed

0-80 degrees/s

Pan Rotation Angle

359degrees

Tilt Rotation Angle

240degrees

Auto Pan Scan

Support

Boundary Scan

0-359degrees (Programmable)

Remoter Control

IR Wireless remote control P/T/Z

Power

DC12V ±10% 1.2A

Operation Temperature

-10℃~60℃

Environmental humidity

0-95%RH(non-condensation)

Length X width X high

124x120x145mm/220x175x220mm(NET/PACKAGE)

Weight

800g/1300g(NET/PACKAGE)
